$13
Car Rear View Camera 4 Pin to RCA Cable Bracket License Plate Lights Housing Mount
The camera is fit:
For Lexus IS300 IS200 (GXE10/JCE10) (does not fit IS Sportcross hatchback) 2001~2005
For Lexus ES300 ES330 (MCV30) 2002~2006
For Lexus GS300 GS400 GS430 (JZS160/UZS161) 1998~2005
For Lexus LS430 LS 430 (UCF30) 2001~2006
For Lexus HS250h HS 250h (ANF10) 2010~2012
For Lexus CT200h (ZWA10) 2011~2014
For Toyota Vios / Yaris Sedan 2007~2013
For Toyota Prius 2001~2003 (NHW11)
Important Note:
1. Please must check the camera size and appearance before place a order.
2. Check if it can match your car license plate lamp place size and appearance.
3. Because the same car model in different countries may have some difference.
4. Please check the camera size and compare the installation of your car carefully to avoid mistake.
Main Features:
1.Image Sensor: New Superhigh Light-sensitive Color High Quality Sensor.
2.Signal System: NTSC.
3.Resolution: 480 TV lines (Enhanced) 648*488 Pixels.
4.Lens Angle: 170 degrees.
5.Sensing Area:3.6mm x 2.7mm.
6.Video Output: 4 pin, 1.0 Vpp composite video.
7.Current Consumption:Max. 150 mA.
8.Working Voltage: 12V DC.
9.Electronic Shutter:1/60(NTSC)~1/100,000 Seconds.
10.Minimum Illumination: 0.3Lux (day), 0Lux (with IR).
11.S/N Ratio: Better than 48 DB.
12.Work Environment: -40 °C~ +80 °C, Rh 95% Max.
13.Anti-vibration:10 g.
14.Power Consumption: 100mA.
15.Active Power: ≥1W.
16.Min. Illumination: 0.1 Lux.
17.Waterproof Grade: IP68 (Protected against ingress of dust and effect of immersion less than 1 meter depth).
18.Special Function: Auto White Blance, AGC, Backlight Compensation.
Package Included:
1 x CCD Car Rear View camera.
1 x general manual.
1 x 4-Pin male to RCA Cable.
